Features of your vehicle 76 4 Engine Coolant Temperature Gauge This gauge indicates the tempera- ture of the engine coolant when the ignition switch or Engine Start/Stop button is ON. If the gauge pointer moves beyond the normal range area toward the “H” position, it indicates overheating that may damage the engine.
Do not continue driving with an over- heated engine. If your vehicle over- heats, refer to “If the Engine Overheats” in chapter 6. Fuel Gauge This gauge indicates the approxi- mate amount of fuel remaining in the fuel tank. ✽ ✽ NOTICE.
The fuel tank capacity is given in chapter 8. The fuel gauge is supplemented by a low fuel warning light, which will illuminate when the fuel tank is nearly empty. On inclines or curves, the fuel gauge pointer may fluctuate or the low fuel warning light may come on earlier than usual due to the movement of fuel in the tank. WARNING - Hot radiator Never remove the radiator cap when the engine is hot. The engine coolant is under pres- sure and could cause severe burns. Wait until the engine is cool before adding coolant to the reservoir. OUM044105 ■ Type A■Type B OUM044106 ■Type A■Type B.
477 Features of your vehicle ✽ ✽NOTICE Fuel display may not be accurate if you are filling in sloping places. Odometer The odometer Indicates the total dis- tance that the vehicle has been driv- en and should be used to determine when periodic maintenance should be performed. Odometer range: 0 1,599,999 kilometers or 999,999 miles.
Outside Temperature Gauge This gauge indicates the current out- side air temperatures by 1°C (1°F). Temperature range: -40°C 60°C (-40°F 140°F) The outside temperature on the dis- play may not change immediately like a general thermometer to pre- vent the driver from being inattentive. WARNING - Fuel gauge Stop and obtain additional fuel as soon as possible after the warning light comes on or when the gauge indicator comes close to the E level. Running out of fuel can expose vehicle occu- pants to danger. CAUTION- Low fuel Avoid driving with an extremely low fuel level.
Running out offuel could cause the engine tomisfire damaging the catalyticconverter. OYP044113K ■ Type A OUM044114 ■Type BOYP044114K ■Type A OUM044115 ■Type B. Features of your vehicle 78 4 To change the temperature unit (from °C to °F or from °F to °C) The temperature unit can be changed by using the 'User Settings' mode of the LCD display. ❈ For more details, refer to “LCD Display” in this chapter.Transaxle Shift Indicator Automatic Transaxle Shift Indicator This indicator displays which auto- matic transaxle shift lever is selected.
Reverse: R Neutral: N Sports Mode: 1, 2, 3, 4, 5, 6 Icy Road Warning Indicator This warning light is to warn the driv- er the road may be icy. When the following conditions occur, the warning light (including Outside Temperature Gauge) blinks 10 times and then illuminates, and also warn- ing chime sounds 3 times. The temperature on the Outside Temperature Gauge is below approximately 4°C (40°F). If the icy road warning light appears while driving, you should drive more attentively and safely refraining from over-speeding, rapid acceleration, sudden braking or sharp turning, etc.OUM04411 ■ Type A■Type B OUMA044430 ■Type A■Type B. 479 Features of your vehicle LCD DISPLAY ❈For controlling the LCD modes, refer to 'LCD Display Control' in this chapter.
LCD Modes Modes SymbolExplanation Trip ComputerThis mode displays driving information like the tripmeter, fuel economy, and so on. For more details, refer to “Trip Computer” in this chapter. Tu r n B y Tu r n (if equipped)This mode displays the state of the navigation. ASCC/LDWS (if equipped) This mode displays the state of the Advanced Smart Cruise Control system (ASCC) and Lane Departure Warning System (LDWS). For more details, refer to 'Advanced Smart Cruise Control system (ASCC)' or 'Lane Departure Warning System (LDWS)' in chapter 5.
A/V (if equipped)This mode displays the state of the A/V system. Information This mode informs of service interval (km or days). This mode informs of warning messages related to washer fluid or malfunction of Blind Spot Detection system (BSD) and so on. When any door is not closed securely, this symbol is illuminated.
Kia Sorento Owners Manual
User SettingsIn this mode, you can change settings of the doors, lamps and so on. Features of your vehicle 80 4 The trip computer is a microcomput- er-controlled driver information sys- tem that displays information related to driving. ✽ ✽ NOTICE Some driving information stored in the trip computer (for example Average Vehicle Speed) resets if the battery is disconnected.
2017 Kia Sorento User Manual
Trip Modes Fuel Economy Range (1) The range is the estimated dis- tance the vehicle can be driven with the remaining fuel. Distance range: 1 9,999 km or 1 9,999 mi. If the estimated distance is below 1km (1mi.), the trip computer will display “-” as range. If the vehicle is not on level ground or the battery power has been interrupted, the range function may not operate correctly. TRIP MODES (TRIP COMPUTER) Digital speedometer To change the trip mode, scroll the TRIP scroll switch (▲/▼) in the trip computer mode. TRIP A TRIP B FUEL ECONOMY OYP044147C. 481 Features of your vehicle The range may differ from the actu-al driving distance as it is an esti- mate of the available driving dis- tance.
The trip computer may not register additional fuel if less than 6 liters (1.6 gallons) of fuel are added to the vehicle. The fuel economy and range may vary significantly based on driving conditions, driving habits, and con- dition of the vehicle. Average Fuel Economy (2) The average fuel economy is calcu- lated by the total driving distance and fuel consumption since the last average fuel economy reset. Fuel economy range: 0.0 99.9MPG or L/100km The average fuel economy can be reset both manually and automati- cally. Manual reset To reset average fuel economy manu- ally, press the OK button (reset) on the steering wheel for more than 1 second when the average fuel econ- omy is displayed. Automatic reset To make the average fuel economy be reset automatically whenever refu- eling, select the “Auto Reset” mode in User Setting menu of the LCD display (Refer to “LCD Display”).
Under “Auto Reset” mode, the aver- age fuel economy will be cleared to zero (-) when the vehicle speed exceeds 1 km/h after refueling more than 6 liters (1.6 gallons). ✽ ✽ NOTICE The average fuel economy is not dis- played for more accurate calculation if the vehicle does not drive more than 10 seconds or 50 meters (0.03 miles) since the ignition switch or Engine Start/Stop button is turned to ON. Instant Fuel Economy (3) This mode displays the instant fuel economy during the last few sec- onds when the vehicle speed is more than 10 km/h (6.2 MPH). Fuel economy range: 0 50 MPGor 0 30 L/100km. Features of your vehicle 82 4 Trip A/B Tripmeter (1) The tripmeter is the total driving dis- tance since the last tripmeter reset. Distance range: 0.0 9999.9 kmor mi. To reset the tripmeter, press the OK button (reset) on the steering wheel for more than 1 second when the tripmeter is displayed.
Average Vehicle Speed (2) The average vehicle speed is cal- culated by the total driving dis- tance and driving time since the last average vehicle speed reset. Speed range: 0 999 km/h or MPH To reset the average vehicle speed, press the OK button (reset) on the steering wheel for more than 1 sec- ond when the average vehicle speed is displayed. ✽ ✽ NOTICE. The average vehicle speed is not dis- played if the driving distance is less than 50 meters (0.03 miles) or the driving time is less than 10 seconds since the ignition switch or Engine Start/Stop button is turned to ON. Even if the vehicle is not in motion, the average vehicle speed keeps going while the engine is running. Timer (3) The elapsed time is the total driv- ing time since the last elapsed time reset. Time range (hh:mm): 00:00 99:59 To reset elapsed time, press the OK button (reset) on the steering wheel for more than 1 second when the elapsed time is displayed.
✽ ✽ NOTICE Even if the vehicle is not in motion, the elapsed time keeps going while the engine is running.OUMA044408C. 483 Features of your vehicle Digital speedometer This mode displays the current speed of the vehicle. One time driving information mode This display shows trip distance (1), average fuel economy (2) and the estimated distance that the vehicle can be driven with the remaining fuel (3). This information is displayed for a few seconds when you turn off the engine and then goes off automati- cally. The information provided is cal- culated according to each trip.If the estimated distance is below 1km, (1mi.) the range (3) will display as '-' and a refuel message will appear (4). OUMA044423C OYP044193C.
485 Features of your vehicle Service Mode Service Interval Service interval It calculates and displays when you need a scheduled maintenance service (km or days). If the remaining km or time reaches 1,500 km (900 mi.) or 30 days. Service interval message is dis- played for several seconds each time you set the ignition switch or Engine Start/Stop Button to the ON position.Service required If you do not have your vehicle serv- iced according to the preset service interval.
“Service required” message is dis- played for several seconds each time you set the ignition switch or Engine Start/Stop Button to the ON position. To reset the service interval to the km and days y ou presetbefore: Press the OK button (reset) for more than 1 second. Service interval OFF If the service interval is not set 'Service interval OFF” message is displayed on the LCD display. If you want to activate Service inter- val function, set the service interval in the User setting mode. For more details, refer to “User set- ting mode' in this chapter.
OYP044314C OYP044119COYP044122N.
